Coherz ATS-100

Automated Clear Aligner Trimming Station

High production efficiency with five axis
Compatible with mainstream design software

Your current location：HOME > PRODUCTS > Orthodontic Intelligent Devices

High production efficiency with five axis

High production efficiency with 5 axis , as fast as 45s per aligner
Consistent output in aligner trim line
Ratio of efficiency to labour: 1：3~5

Compatible with mainstream design software

Smoother aligner edge finish, much less/easier post-polishing
Automatically generate trimming trajectory along gingival line
Adjustable curvature of trimming line
Compatible to mainstream CAD softwares in dental application

Collection of oral cavity data of the patient
Design Center Development of treatment planning scheme
Import treatment planning scheme to Coherz LabMagic Software, export tooth models and trimming files in batches
Make tooth models by 3D printer

Conduct edge polishing if necessary depending on materials
Remove the trimmed aligners from tooth models
Run Coherz ATS-100 to trim aligners automatically
Perform aligner thermoforming on tooth models

Coherz ATS-100 Technical Data

X Axis	90mm
Y Axis	90mm
Z Axis	90mm
A Axis	0-90°
C Axis	+360°

Rotational Speed of Spindle	30,000 r/min
Equipment Size	550mm550mm550mm
Voltage	AC220V
Power	120W
Weight	65KG
